CC Series Cone Crusher

Type:Intermediate crusher Feed Size:35mm-460mm

Capacity:27-1531t/h

Materials:Iron ore, copper ore, slag, pebbles, quartz, granite, basalt, dolerite, etc.

Applications:Metallurgical industry, hydro-dam construction, transportation, chemical industry, building, etc.

We're here to help:

Easy ways to get the answers you need.

Get price

OVERVIEW

CC series cone crusher adopts advanced technology. It is widely used in metallurgical industry, hydro-dam construction, transportation, chemical industry and building material industry. It is suitable for crushing all sorts of rocks with different hardness.

FEATURES

1. Reasonable structure, developed crushing principle, advanced technical data, reliable operation and low production cost;
2. High crushing efficiency and large production capacity;
3. Reliable spring insurance system can provide effective overload protection.
4. Various crushing chamber structures can meet different size requirements.
5. Manual hydraulic discharge hole is convenient and labor saving.

TECHNICAL DATA

Model
Type of Cavity
Max Feeding Size(mm)
Discharge range opening(mm)
Motor Power(kw)
Open circuit,Close side(mm),Capacity(t/h)
3
5
6
10
13
16
19
25
31
38
52
64
76
89
CC539
C
155
25~38
75







128
147
175




M
150
13~31




59
73
91
118
137





F
87
9~19



46
59
73
82







CC539D
C
70
6~19
75


59
73
95
114
127







M
51
5~16

41
55
68
91
100








F
35
3~13
27
41
55
68
91









CC551
EC
260
25~52
200







237
273
324
398



C
220
19~52






173
218
250
295
365



M
180
16~38





132
59
200
228
253




F
120
13~31




109
127
146
163
181





CC551D
C
90
8~25
200



109
159
182
200
228






M
76
6~16


82
105
137
164








F
55
3~16
36
59
82
105
137
164








CC567
EC
315
38~64
250









538
630
743


C
230
25~64







354
417
454
610
637


M
205
22~52







291
337
381
438



F
180
16~38





182
205
259
296
327




CC567D
EC
115
13~25
250




255
282
309
337






C
115
10~25



191
255
282
309
337






M
76
6~19


137
164
209
255
282







F
60
5~13

91
1137
164
209









CC584
EC
460
38~89
400









800
1179
1361
1473
1531
C
310
31~76








789
844
1088
1257
1386

M
280
25~64







608
762
807
998
1128


F
235
19~52






381
499
617
726
852



CC584D
EC
170
16~25
400





508
590
653






C
150
13~25




454
480
540
599






M
110
10~19



354
408
454
508







F
90
5~16

190
270
345
360
408









Note:
The capacity is total tons per hour passing through crusher at open circuit when crushing medium and below hardness material and bulk density with 1.6x10³kg/m³.Capacities are relative to physical character and type of feeding,feeding size and composition and so on.
